AS3 ToolTip

I've been busy living my other life as a programmer and haven't done too much drawing... I'm busy at work on a project that allows you to do lots of drawing over the Internet but I can't tell you anymore than that. But I want to share something with everyone. Here's a super lightweight AS3 ToolTip class that's easy to use and easy to customize. It uses some neat tricks too so if you want to learn some AS3 black magic take a close look.

package {

import flash.display.Sprite;
import flash.text.TextField;
import flash.text.TextFormat;
import flash.text.TextFieldAutoSize;
import flash.text.TextLineMetrics;
import flash.display.BlendMode;
import flash.utils.Timer;

public class ToolTip extends Sprite {

private var _tip:String;

// You'll need this for proper text formatting
private var _tf:TextField = new TextField();
private var _format:TextFormat = new TextFormat();

private static const ROUND:Number = 2;
private static const HEIGHT:Number = 25;
private static const FONT_SIZE:uint = 14;
private static const FONT:String = 'Arial';
private static const PADDING:Number = 5;
private static const MIN_ALPHA:Number = .00;
private static const ALPHA_INC:Number = .05;
private static const MAX_ALPHA:Number = .75;
private static const REFRESH:Number = MAX_ALPHA / ALPHA_INC;

// For fading in and out
private var _timer:Timer;

public function ToolTip( tip:String ) {

// Hold onto the tip for posterity
_tip = tip;

// This ensures the textfield inherits this class's
// alpha property. Very important because otherwise tf
// would always have an alpha of 1 meaning it will always be visible
this.blendMode = BlendMode.LAYER;

_format.size = FONT_SIZE;
_format.font = FONT;

// Make sure the text behaves and looks
// the way text on a button should
_tf.defaultTextFormat = _format; // Always call defaultTextFormat before setting text otherwise
// the text doesn't use the formatting defined in tf

_tf.autoSize = TextFieldAutoSize.LEFT; // You have to set autoSize to TextFieldAutoSize.LEFT
// for box.textWidth to be accurate
_tf.multiline = false;
_tf.text = tip;
_tf.selectable = false;
_tf.x += PADDING;
_tf.y += PADDING;
addChild( _tf );

// Draw the background
graphics.beginFill( 0xFFFFFF, 1 );
graphics.drawRoundRect( 0, 0, _tf.textWidth+PADDING*4, HEIGHT, ROUND );
this.alpha = MIN_ALPHA;

// You have to call this after
// the tooltip has been added to the
// display list
public function start():void {
this.parent.addEventListener( MouseEvent.MOUSE_OVER, mouse_over );

public function mouse_over( e:MouseEvent ):void {
this.parent.setChildIndex( this, this.parent.numChildren-1 ) // Move the tool tip to the top!
var fadeSpeed:Number = 500 / REFRESH;
_timer = new Timer( fadeSpeed, REFRESH );
_timer.addEventListener( "timer", fadeIn )
this.parent.addEventListener( MouseEvent.MOUSE_OUT, mouse_out );

public function mouse_out( e:MouseEvent ):void {
var fadeSpeed:Number = 500 / REFRESH;
_timer = new Timer( fadeSpeed, REFRESH );
_timer.addEventListener( "timer", fadeOut )

private function fadeIn( i:uint ):void {
this.alpha += ALPHA_INC;

private function fadeOut( i:uint ):void {
this.alpha -= ALPHA_INC;

Using it in your code is this easy.

// Construct a tooltip
var toolTip:ToolTip = new ToolTip( 'This thingy does remarkable things when pressed' );

// Add the tooltip to the display object you want to give a tip about
thingy.addChild( toolTip );

// Start the tooltip


sou eu.. Luana said...

Hi!! thanks for this tutorial! But i had a problem,

I received this message: "1137: Incorrect number of arguments. Expected no more than 0."

on this line:
var toolTip:ToolTip = new ToolTip( 'test' );

Adam T said...

I don't know why you would get that error. The ToolTip constructor you're calling needs exactly one argument.

public function ToolTip( tip:String ) {

I'd double check the syntax of the rest of your code.

Good luck!

zac said...

Hello, thanks for sharing that. It seems very nice but it is not working.
I put the as file in the same folder of the .fla file.
I get the following errors:

1046: Type was not found or was not a compile-time constant:
1180: Call to a possibly undefined method ToolTip.ToolTip.
1061: Call to a possibly undefined method addChild through a reference with static type flash.display:SimpleButton.

Is it a referencing error ?

Adam T said...


I use the Flex command line compiler on my projects. You're using the Flash authoring environment. Importing classes are a little different between the two so what you need to do is remove the lines 'package {' and the closing brace on the final line '}'.

Then you'll need to add this line to your actions 'import'.

You can read more about this here.

beBopper said...

This doesn't work in Flash CS3 AS3.

If you "import" it says: 1084: Syntax error: expecting identifier before as.

If you "import tooltip" you don't get an error, but then when you try to use it, you get the error: 1180: Call to a possibly undefined method ToolTip.

beBopper said...

removing package { and the last } had no effect.

1046: Type was not found or was not a compile-time constant: ToolTip.
1180: Call to a possibly undefined method ToolTip.
1061: Call to a possibly undefined method addChild through a reference with static type flash.text:TextField.

Anonymous said...

Excuse my english.... i had problems with this code. "Type was not found or was not a compile-time constant: ToolTip" It's because the class name ToolTip have a capital letter in the middle. I change the name of the class for Tooltip and it's works very well. Thank you!!

William said...

How do i stop the transparent problem with tool tip?
